Intare Video | 2 x 6G-SDI |
Iesire Video | 1 x HDMI type A 1 x 6G-SDI |
Multi-Rate Support | Auto detection of SD, HD, or 4K signals |
Reclocking | Yes |
Iesire Audio | Analog: 2 channels with 1 x 1/4" jack per channel AES/EBU: 4 channels with 1 x 1/4" jack |
Format Support | DCI 4K 24p UHD 4K 3840 x 2160p: 30/29.97/25/24/23.98 HD 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50 SD NTSC: 525i/59.94 PAL: 625i/50 |
Conformitate SDI | SMPTE 259M/292M/296M/372M/424M/425M Level A or Level B/SMPTE ST-2081 |
SDI Video Rates | SDI video connections are switchable between standard definition, high definition, Level A or Level B 3G-SDI and 6G-SDI. |
SDI Video Sampling | 4:2:2 4:4:4 |
SDI Color Precision | 4:2:2 4:4:4 |
SDI Color Space | YUV RGB |
SDI Audio Sampling | 24-bit, 48 kHz |
SDI Auto Switching | Automatically detects SD, HD, or 6G-SDI |
Rezolutii suportate HDMI | UHD 4K 3840 x 2160p: 30/29.97/25/24/23.98 HD 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50 SD NTSC: 525i/59.94 PAL: 625i/50 |
HDMI Color Space | YUV and RGB |
HDMI Color Precision | 4:2:2 4:4:4 |
Format conversie | HD down-conversion |
Control setari | Mini switches or USB software |
Upgrade Firmware | Via USB |
Putere | 12 VDC |
Consum putere | 5.2 W |
Voltaj operational | 12 la 31 VDC |
Temperatura functionare | 0 la 40°C |
Temperatura depozitare | -20 la 45°C |
Umiditate admisa | 0 la 90% fara condens |
Dimensiuni | 11.40 x 9.22 x 2.29 cm |
Greutate | 256.85 g |
