Durata de livrare: 1-2 zile pentru produsele aflate in stoc
Intrare Video | 1 x HDMI, Type A |
Iesire Video | 2 x 6G-SDI |
Multi-Rate Support | Detecteaza automat semnal SD, HD, 3G, or 6G-SDI signals |
Reclocking | Da |
Intrare Audio | Analog: 2 channels with 1 x 1/4" jack per channel AES/EBU: 4 channels with 1 x 1/4" jack |
Rezolutii suportate | DCI 4K 24p UHD 4K 3840 x 2160p: 30/29.97/25/24/23.98 HD 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50 SD NTSC: 525i/59.94 PAL: 625i/50 |
Standard SDI | SMPTE 259M/292M/296M/372M/424M/425M Level A or B/SMPTE ST-2081 ITU-R BT.656 and ITU-R BT.601 |
SDI Video Rates | Switchable between SD, HD, Ultra HD and DCI 4K |
SDI Video Sampling | 4:2:2 |
SDI Color Precision | 4:2:2 |
SDI Color Space | YUV |
SDI Audio Sampling | 24-bit, 48 kHz |
SDI Auto Switching | Automatically detects SD, HD, or 6G-SDI |
HDMI Format Support | UHD 4K 3840 x 2160p: 30/29.97/25/24/23.98 HD 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50 SD NTSC: 525i/59.94 PAL: 625i/50 |
HDMI Color Space | YUV and RGB |
HDMI Color Precision | 4:2:2 4:4:4 |
HDCP Compliance | No. HDMI input is unable to capture from copy-protected HDMI sources |
Format Conversion | HD down-conversion |
Setari control | Mini switches or USB software |
Update Firmware | Via USB |
Putere | 12 VDC |
Putere de consum | 4.44 W |
Voltaj operational | 12 la 31 VDC |
Temperatura operare | 0 la 40 °C |
Temperatura depozitare | -20 la 45 °C |
Umiditate admisa | 0 la 90% fara condens |
Dimensiuni | 11.40 x 9.22 x 2.29 cm |
Greutate | 243.8 g |
